Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1704A 2 Position Off-(On)
FE-A1704
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1703A 2 Position On- On
FE-A1703B 3 Position (On)-Off-On
FE-A1703C 3 Position (On)-Off-(On)
FE-A1703
FE-A1702
Single Pole Single Throw Switch
2 Position On-Off
2 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1701A 2 Position Off-(On)
FE-A1701
TOGGLE SWITCH
FE-A1708
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Nickel plated Bronze Contacts
Rating : 10Amps @ 125Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1708A 2 Position Off-(On)
Double Pole Double Throw Switch
3 Position On-Off-On
6 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1707A 2 Position On-On
FE-A1707B 3 Position (On)-Off-On
FE-A1707C 3 Position (On)-Off-(On)
FE-A1707
Double Pole Double Throw Switch
3 Position On-Off-On
6 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1706A 2 Position On-On
FE-A1706B 3 Position (On)-Off-On
FE-A1706C 3 Position (On)-Off-(On)
FE-A1706
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1705A 2 Position Off-(On)
FE-A1705
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1713A 2 Position Off-(On)
FE-A1713
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1712A 2 Position On-On
FE-A1712B 3 Position (On)-Off-On
FE-A1712C 3 Position (On)-Off-(On)
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Nickel plated Bronze Contacts
Rating : 10Amps @ 125Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1711A 2 Position On-On
FE-A1711B 3 Position (On)-Off-On
FE-A1711C 3 Position (On)-Off-(On)
FE-A1711
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1710A 2 Position Off-(On)
FE-A1710
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1709A 2 Position Off-(On)
FE-A1718
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1718A 2 Position On-On
FE-A1718B 3 Position (On)-Off-On
FE-A1718C 3 Position (On)-Off-(On)
FE-A1717
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1717A 2 Position Off-(On)
FE-A1716
Double Pole Double Throw Switch
3 Position On-Off-On
6 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1716A 2 Position On-On
FE-A1716B 3 Position (On)-Off-On
FE-A1716C 3 Position (On)-Off-(On)
Double Pole Double Throw Switch
3 Position On-Off-On
6 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1715A 2 Position On-On
FE-A1715B 3 Position (On)-Off-On
FE-A1715C 3 Position (On)-Off-(On)
FE-A1715
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1714A 2 Position Off-(On)
FE-A1714
FE-A1723
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Copper Contacts
Rating : 50Amps @ 6-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1723A 2 Position Off-(On)
FE-A1722
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1722A 2 Position On-On
FE-A1722B 3 Position (On)-Off-On
FE-A1722C 3 Position (On)-Off-(On)
FE-A1721
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1721A 2 Position Off-(On)
FE-A1720
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Copper Contacts
Rating : 50Amps @ 6-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1720A 2 Position On-On
FE-A1720B 3 Position (On)-Off-On
FE-A1720C 3 Position (On)-Off-(On)
FE-A1719
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Copper Contacts
Rating : 50Amps @ 6-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1719A 2 Position Off-(On)
FE-A1729
FE-A1728
FE-A1727
FE-A1725
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Copper Contacts
Rating : 50Amps @ 6-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1725A 2 Position On-On
FE-A1725B 3 Position (On)-Off-On
FE-A1725C 3 Position (On)-Off-(On)
FE-A1724
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Copper Contacts
Rating : 50Amps @ 6-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1724A 2 Position On-On
FE-A1724B 3 Position (On)-Off-On
FE-A1724C 3 Position (On)-Off-(On)
FE-A1734
FE-A1733
FE-A1732
FE-A1731
FE-A1730
FE-A1740
FE-A1739
FE-A1738
FE-A1737
FE-A1736
FE-A1747
FE-A1746
FE-A1745
FE-A1744
FE-A1741
FE-A1754
FE-A1752
FE-A1751
FE-A1750
FE-A1748
FE-A1753
FE-A1749
FE-A1742
Dimemsions in m/m
Single Pole Single Throw Switch
2 Position On-Off
2 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1702A 2 Position Off-(On)
(11.11m/m)
(11.11m/m)
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Rating : 3Amps @ 125Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Rating : 3Amps @ 125Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Iron Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1750A 2 Position Off-(On)
Double Pole Single Throw Switch
3 Position Off-On-(On)
4 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
With Boot Nut and Special Moisture-Proof
Double Pole Double Throw Switch
3 Position On-Off-On
6 Screw terminals
Rating : 10Amps @ 125Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Rating : 2Amps @ 250Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
Head Light Switch
3 Position Off-On(I)-On(II)
3 Pin terminals
Copper Contacts
Application : Austin Taxi(Fairway)
'86-'87 JIV01-99029
3 Position On-Off-On
5 Blade terminals
Copper Contacts
Rating : 12-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
Replaces Lucas Part No. 31788
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
Application : Merit 32100
Double Pole Single Throw Switch
3 Position Off-On-On
4 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
With Boot Nut and Special Moisture-Proof
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
With Boot Nut and Special Moisture-Proof
Single Pole Single Throw Switch
Same as FE-A1744 but with Waterproof Rubber Cover
2 Position Off-On
2 Blade terminals
Silver Plated Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
With Boot Nut
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Silver Plated Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
One Switch
2 Position Off-On
3 Blade terminals
Switch in Plastic Panel
2 Colors : Red / Green
With Bulb
One Switch
2 Position Off-On
2 Blade terminals
Switch in Steel Panel
Single Pole Single Throw Switch
2 Position Off-On
3 Blade terminals
Copper Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 1/4” Long
4 Colors : Red / Amber / Green / Blue
With Bulb
Single Pole Double Throw Switch
2 Position On-On
3 Blade terminals
Copper Contacts
Rating : 10Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 1/4” Long
FE-A1728A 3 Position On-Off-On
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Copper Contacts
Rating : 10Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 1/4” Long
FE-A1727A 2 Position Off-(On)
Long Type Horn Switch
Single Pole Single Throw Switch
2 Position Off-(On)
2 Blade terminals
Copper Contacts
Mounting Stem : 15/32” Diameter / 15/32” Long
Short Type Horn Switch
Single Pole Single Throw Switch
2 Position Off-(On)
2 Blade terminals
Copper Contacts
Mounting Stem : 15/32” Diameter / 15/32” Long
Application : Merit 32100
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Copper Contacts
Rating : 15Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 1/4” Long
Single Pole Single Throw Switch
2 Position Off-On
3 Blade terminals
Rating : 10Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 1/4” Long
4 Colors : Red / Yellow / Green / Blue
With LED
Single Pole Single Throw Switch
2 Position Off-On
3 Blade terminals
Copper Contacts
Rating : 10Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 1/4” Long
5 Colors : Red / Yellow / Green / Blue / Black
With Bulb
FE-A1730A-BK 3 Pin SPDT / 3 Position On-Off-On
FE-A1730B-BK 3 Pin SPDT / 2 Position On-On
FE-A1730C-BK 2 Pin SPST / 2 Position Off-On
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Bronze Contacts
Mounting Stem : 15/32” Diameter / 15/32” Long
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Bronze Contacts
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 3Amps @ 250Volts AC / 6Amps @ 125Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1755
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 3Amps @ 250Volts AC / 6Amps @ 125Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1756
FE-A1757
FE-A1758
FE-A1759
FE-A1761
FE-A1760
FE-A1762
FE-A1763
FE-A1764
FE-A1765
FE-A1766
FE-A1767
FE-A1769
FE-A1768
(14.3m/m)
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
FE-A1769A 2 Position Off-(On)
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Silver plated Bronze Contacts
3 Position On-Off-On
6 Blade terminals
Copper Contacts
Rating : 12-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
Replaces Lucas Part No. 35927
3 Position On-Off-On
3 Blade terminals
Copper Contacts
Rating : 12-24Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
Replaces Lucas Part No. 31743
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Copper Contacts
Rating : 12-24Volts DC
Replaces Lucas Part No. 34889
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Copper Contacts
Replaces Lucas Part No. SPB200
Single Pole Single Throw Switch
2 Position Off-(On)
2 Blade terminals
Silver plated Bronze Contacts
Replaces Lucas Part No. SPB204
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Bronze Contacts
Rating : 10Amps @ 250Volts AC / 15Amps @ 125Volts AC
FE-A1768A 2 Position On-On
FE-A1768B 3 Position (On)-Off-On
FE-A1768C 3 Position (On)-Off-(On)
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1756A 2 Position On-On
FE-A1756B 3 Position (On)-Off-On
FE-A1756C 3 Position (On)-Off-(On)
3 Pole Double Throw Switch
3 Position On-Off-On
9 Blade terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
2 Position Off-On
2 Cable terminals
Rating : 4Amps @ 250Volts AC / 8Amps @ 125Volts AC
Mounting Stem : 15/32” Diameter / 15/32” Long
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Bronze Contacts
3 Pole Double Throw Switch
3 Position On-Off-On
9 Screw terminals
Bronze Contacts
Single Pole Single Throw Switch
2 Position Off-On
2 Wires
Rating : 10Amps @ 125Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1708 With special Moisture-Proof
FE-A1759A FE-A1708A With special Moisture-Proof / 2 Position Off-(On)
FE-A1770
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
1770 Series Test Report
FE-A1771
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
FE-A1771A 2 Position On-On
FE-A1771B 3 Position (On)-Off-On
FE-A1771C 3 Position (On)-Off-(On)
FE-A1771D 2 Position On-(On)
FE-A1772
FE-A1773
FE-A1774
FE-A1775
FE-A1776
FE-A1777
FE-A1778
FE-A1779
FE-A1780
FE-A1781
FE-A1782
FE-A1783
FE-A1784
FE-A1785
FE-A1786
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
Double Pole Double Throw Switch
3 Position On-Off-On
6 Screw terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
Double Pole Double Throw Switch
3 Position On-Off-On
6 Blade terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Nickel plated Bronze Contacts
Rating : 20Amps @ 12Volts DC
FE-A1778A 2 Position On-On
FE-A1778B 3 Position (On)-Off-On
FE-A1778C 3 Position (On)-Off-(On)
FE-A1778D 2 Position On-(On)
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Silver plated Bronze Contacts
Max. current / Voltage rating with resistive load :
12Amps @ 28Volts DC – 6Amps @ 250Volts AC
Initial contact resistance : 10mΩ Max. 1Amps @ 2Volts DC
Insulation resistance : 1.000MΩ min. 500Volts DC
Waterproof
Single Pole Double Throw Switch
Same as FE-A1778 but with Waterproof Rubber Cover
3 Position On-Off-On
3 Blade terminals
Nickel plated Bronze Contacts
Rating : 20Amps @ 12Volts DC
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Copper Contacts
Replaces Lucas Part No. 31780
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Nickel plated Bronze Contacts
Rating : 20Amps @ 12Volts DC
FE-A1781A 2 Position Off-(On)
Single Pole Single Throw Switch
2 Position Off-On
2 Pin
Rating : 3Amps @ 250Volts AC
Double Pole Double Throw Switch
3 Position On-Off-On
6 Blade terminals
Nickel plated Bronze Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
FE-A1783A 2 Position On-On
FE-A1783B 3 Position (On)-Off-On
FE-A1783C 3 Position (On)-Off-(On)
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Nickel plated Bronze Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Nickel plated Bronze Contacts
Rating : 15Amps @ 24Volts DC
FE-A1785B 3 Position (On)-Off-On
FE-A1785C 3 Position (On)-Off-(On)
FE-A1787
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Copper Contacts
FE-A1788
FE-A1789
FE-A1790
FE-A1791
FE-A1792
FE-A1793
FE-A1794
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Nickel plated Bronze Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
FE-A1789A 2 Position Off-(On)
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Copper Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Copper Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Copper Contacts
Rating : 20Amps @ 12Volts DC /15Amps @ 24Volts DC
Double Pole Double Throw Switch
3 Position On-Off-On
6 Screw terminals
Copper Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
FE-A1787A 2 Position Off-(On)
Double Pole Double Throw Switch
3 Position On-Off-On
6 Screw terminals
Bronze Contacts
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
FE-A1788A 2 Position On-On
FE-A1788B 3 Position (On)-Off-On
FE-A1788C 3 Position (On)-Off-(On)
FE-A1796
FE-A1797
FE-A1797C
FE-A1797C-1
FE-A1798
FE-A1799
FE-A17200
FE-A17201
FE-A17202
FE-A17205
FE-A17204
FE-A17203
FE-A17208
FE-A17207
FE-A17206
FE-A17209
FE-A5701
FE-A5702
FE-A5704
Single Pole Single Throw Switch
Same as FE-A1797 but with Waterproof Rubber Cover
2 Position Off-On
2 Blade terminals
Silver plated Bronze Contacts
Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC
Single Pole Single Throw Switch
2 Position Off-(On)
2 Blade terminals
Copper Contacts
Double Pole Double Throw Switch
2 Position Off-On
6 Blade terminals
Bronze Contacts
Single Pole Double Throw Switch
2 Position On-On
3 Pin
Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC
Double Pole Single Throw Switch
3 Position (On)-Off-On
4 Screw terminals
Bronze Contacts
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Silver plated Bronze Contacts
Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC
Single Pole Single Throw Switch
Same as FE-A1797 but with Waterproof Rubber Cover
2 Position Off-On
2 Blade terminals
Silver plated Bronze Contacts
Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC
Single Pole Single Throw Switch
2 Position Off-On
2 Wires
Rating : 20Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1702 With special Moisture-Proof
Single Pole Double Throw Switch
3 Position On-Off-On
3 Wires
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1712 With special Moisture-Proof
FE-A5702A FE-A1703A With special Moisture-Proof / 2 Position On-On
FE-A5702B FE-A1703B With special Moisture-Proof / 3 Position (On)-Off-On
FE-A5702C FE-A1703C With special Moisture-Proof / 3 Position (On)-Off-(On)
Double Pole Double Throw Switch
3 Position On-Off-On
6 Wires
Rating : 25Amps @ 12Volts DC
Mounting Stem : 15/32” Diameter / 15/32” Long
FE-A1715 With special Moisture-Proof
FE-A5704A FE-A1715A With special Moisture-Proof / 2 Position On-On
FE-A5704B FE-A1715B With special Moisture-Proof / 3 Position (On)-Off-On
FE-A5704C FE-A1715C With special Moisture-Proof / 3 Position (On)-Off-(On)
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Lever Type : Bronze / Plastic
FE-A17200A 2 Position Off-(On)
Single Pole Double Throw Switch
3 Position On-Off-On
3 Screw terminals
Lever Type : Bronze / Plastic
FE-A17201A 2 Position On-On
FE-A17201B 3 Position (On)-Off-On
Double Pole Single Throw Switch
2 Position Off-On
4 Screw terminals
Lever Type : Bronze / Plastic
Double Pole Double Throw Switch
3 Position (On)-Off-(On)
6 Screw terminals
Lever Type : Bronze / Plastic
8 Screw terminals
Lever Type : Bronze / Plastic
4 Pole Double Throw Switch
3 Position On-Off-On
12 Screw terminals
Lever Type : Bronze / Plastic
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Lever Type : Bronze / Plastic
FE-A17206A 2 Position Off-(On)
Single Pole Double Throw Switch
3 Position On-Off-On
3 Blade terminals
Lever Type : Bronze / Plastic
FE-A17207A 2 Position On-On
FE-A17207B 3 Position (On)-Off-On
FE-A17207C 3 Position (On)-Off-(On)
Double Pole Single Throw Switch
2 Position Off-On
4 Blade terminals
Lever Type : Bronze / Plastic
Double Pole Double Throw Switch
3 Position On-Off-On
6 Blade terminals
Lever Type : Bronze / Plastic
FE-A17209A 2 Position On-On
FE-A17209C 3 Position (On)-Off-(On)
